Urban Track is a threephase linear track luminaire available in lengths of 570mm, 840mm and 1.130mm with 21W, 32W and 43W of power respectively. It is designed for threephase track installation and offers two aperture angles of 78° (UGR) and 112° (OPAL) that direct the light downward and provide precise or wider light as required. The 78° opening angle (UGR) has a UGR<19 index that minimizes glare.
This linear track luminaire is available in fixed color temperatures ranging from 2.700K to 5.000K and dimmable CCT between 2.700K and 5.500K. It offers a choice of Casambi and Push technologies that ensure intelligent and precise light control. In addition, CRI>95 certification ensures faithful color rendering.
Urban Track includes an integrated driver and is delivered ready for installation. It offers customized cutting and handling with a maximum size of 3,37m and can also be customized in terms of color by our production department using the RAL palette.
Finishes and colours
Technical specifications
Rated power
21 W / 32 W / 43 W
Colour temperature
2700K / 3000K / 4000K / 5000K
Lumens
From 2352 to 5848
Lifespan
50000
Efficacy (lm/W)
112 / 128 / 136
CRI
>95
IP
IP20
UGR
<19 / >22
Catalogue references
Code
Name
644241
URBAN TRACK 570mm 21W UGR 78º ON/OFF 2700K WHITE
644242
URBAN TRACK 570mm 21W UGR 78º ON/OFF 2700K BLACK
644261
URBAN TRACK 570mm 21W UGR 78º CASAMBI 2700K WHITE
644262
URBAN TRACK 570mm 21W UGR 78º CASAMBI 2700K BLACK
644341
URBAN TRACK 570mm 21W UGR 78º ON/OFF 3000K WHITE
644342
URBAN TRACK 570mm 21W UGR 78º ON/OFF 3000K BLACK
644361
URBAN TRACK 570mm 21W UGR 78º CASAMBI 3000K WHITE
644362
URBAN TRACK 570mm 21W UGR 78º CASAMBI 3000K BLACK
644441
URBAN TRACK 570mm 21W UGR 78º ON/OFF 4000K WHITE
644442
URBAN TRACK 570mm 21W UGR 78º ON/OFF 4000K BLACK
644461
URBAN TRACK 570mm 21W UGR 78º CASAMBI 4000K WHITE
644462
URBAN TRACK 570mm 21W UGR 78º CASAMBI 4000K BLACK
644541
URBAN TRACK 570mm 21W UGR 78º ON/OFF 5000K WHITE
644542
URBAN TRACK 570mm 21W UGR 78º ON/OFF 5000K BLACK
644561
URBAN TRACK 570mm 21W UGR 78º CASAMBI 5000K WHITE
644562
URBAN TRACK 570mm 21W UGR 78º CASAMBI 5000K BLACK
646241
URBAN TRACK 840mm 32W UGR 78º ON/OFF 2700K WHITE
646242
URBAN TRACK 840mm 32W UGR 78º ON/OFF 2700K BLACK
646261
URBAN TRACK 840mm 32W UGR 78º CASAMBI 2700K WHITE
646262
URBAN TRACK 840mm 32W UGR 78º CASAMBI 2700K BLACK
646341
URBAN TRACK 840mm 32W UGR 78º ON/OFF 3000K WHITE
646342
URBAN TRACK 840mm 32W UGR 78º ON/OFF 3000K BLACK
646361
URBAN TRACK 840mm 32W UGR 78º CASAMBI 3000K WHITE
646362
URBAN TRACK 840mm 32W UGR 78º CASAMBI 3000K BLACK
646441
URBAN TRACK 840mm 32W UGR 78º ON/OFF 4000K WHITE
646442
URBAN TRACK 840mm 32W UGR 78º ON/OFF 4000K BLACK
646461
URBAN TRACK 840mm 32W UGR 78º CASAMBI 4000K WHITE
646462
URBAN TRACK 840mm 32W UGR 78º CASAMBI 4000K BLACK
646541
URBAN TRACK 840mm 32W UGR 78º ON/OFF 5000K WHITE
646542
URBAN TRACK 840mm 32W UGR 78º ON/OFF 5000K BLACK
646561
URBAN TRACK 840mm 32W UGR 78º CASAMBI 5000K WHITE
646562
URBAN TRACK 840mm 32W UGR 78º CASAMBI 5000K BLACK
648241
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 2700K WHITE
648242
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 2700K BLACK
648261
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 2700K WHITE
648262
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 2700K BLACK
648341
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 3000K WHITE
648342
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 3000K BLACK
648361
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 3000K WHITE
648362
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 3000K BLACK
648441
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 4000K WHITE
648442
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 4000K BLACK
648461
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 4000K WHITE
648462
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 4000K BLACK
648541
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 5000K WHITE
648542
URBAN TRACK 1130mm 43W UGR 78º ON/OFF 5000K BLACK
648561
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 5000K WHITE
648562
URBAN TRACK 1130mm 43W UGR 78º CASAMBI 5000K BLACK
654241
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 2700K WHITE
654242
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 2700K BLACK
654261
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 2700K WHITE
654262
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 2700K BLACK
654341
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 3000K WHITE
654342
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 3000K BLACK
654361
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 3000K WHITE
654362
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 3000K BLACK
654441
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 4000K WHITE
654442
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 4000K BLACK
654461
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 4000K WHITE
654462
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 4000K BLACK
654541
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 5000K WHITE
654542
URBAN TRACK 570mm 21W OPAL 112º ON/OFF 5000K BLACK
654561
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 5000K WHITE
654562
URBAN TRACK 570mm 21W OPAL 112º CASAMBI 5000K BLACK
656241
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 2700K WHITE
656242
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 2700K BLACK
656261
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 2700K WHITE
656262
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 2700K BLACK
656341
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 3000K WHITE
656342
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 3000K BLACK
656361
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 3000K WHITE
656362
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 3000K BLACK
656441
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 4000K WHITE
656442
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 4000K BLACK
656461
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 4000K WHITE
656462
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 4000K BLACK
656541
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 5000K WHITE
656542
URBAN TRACK 840mm 32W OPAL 112º ON/OFF 5000K BLACK
656561
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 5000K WHITE
656562
URBAN TRACK 840mm 32W OPAL 112º CASAMBI 5000K BLACK
658241
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 2700K WHITE
658242
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 2700K BLACK
658261
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 2700K WHITE
658262
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 2700K BLACK
658341
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 3000K WHITE
658342
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 3000K BLACK
658361
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 3000K WHITE
658362
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 3000K BLACK
658441
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 4000K WHITE
658442
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 4000K BLACK
658461
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 4000K WHITE
658462
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 4000K BLACK
658541
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 5000K WHITE
658542
URBAN TRACK 1130mm 43W OPAL 112º ON/OFF 5000K BLACK
658561
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 5000K WHITE
658562
URBAN TRACK 1130mm 43W OPAL 112º CASAMBI 5000K BLACK
